> Z1 Thermal Inkjet Printer

Description

Z1 – The Compact Solution To Your High Resolution Printing Needs

Z1 – the new Zanasi high resolution coding system, based on Thermal Inkjet (TIJ) technology – is the most suitable solution for a clear and clean industrial printing of barcodes, logos and alphanumerical texts on primary packaging and multiple packaging both on porous and non-porous surfaces (paper, aluminum, flexible film, plastic and coated cases, labels).

The Z1 system grants very high definition printing (up to 900 dpi horizontal – 600 dpi vertical) of complex messages 12.5 mm high. The printhead, one-of-a-kind, can be placed up to 9 mm distant from the product!

The stainless steel structure is small in size (it weighs only a little more than a pound!), with integrated sensor for product detection, guarantees an easy integration on all production lines and can be installed for downwards, upwards and sideways (from 0° to 90°) printing.

The Z1 system is easy to set-up, use and maintain. It is always ready to use, plug & play, manages a range of rapid dry and high adhesion inks through smart ink cartridges.

The cartridges have a chip that automatically recognizes the kind of ink the system is using. The visual ink level indicator ensures full ink use without waste and ensures prompt replacement when empty.

The Z1 system can be managed and controlled remotely through the Z1 Remote Manager software, a powerful and intuitive software for easy message creation and remote control of the system. The Z1 system can manage nearly an infinite number of printheads simultaneously.

Photo Gallery:

Please follow and like us:

Specifications

PRINTING CHARACTERISTICS

Print height from 1 to 12.5 mm (0.04” – 0.5”)
Line speed capability: up to 90 mt/min* (295 ft/min)
Available fonts: Windows True Type
High quality graphic images printing
Internal storage up to 9 messages
Automatic date, time, off sets and expiry date multi-functions
Incrementing/decreasing alphanumeric product counters up to 8 digits
Repeat print – message function
Field orientation: 0°, 90°, 180°, 270°
Fixed and variable text field types and bar codes (automatic or external)
Coding throw distance up to 9 mm (0.35”)

BARCODES (LINEAR AND 2D)

EAN 8, EAN 13, EAN 128, Code 2/5, Code 2/5 check, Code 39, Code 39 check, Code 128, DUN14, GS1 Databar, Datamatrix*, GS1 Datamatrix*, QR-Code*, GS1 Databar* (* Pro Version)

GENERAL FEATURES

Intuitive message creation with Z1 Remote Manager software
Data transfer using USB key
Simplified images and texts formatting with Stretch and Drag & Drop function
Print parameters stored within each message
Multi printhead management through Z1 Remote Manager software
Communication to managements programs and software
Operator interface with extended foreign languages: English, Spanish, French, Italian, German and Japanese
Auto real-time printing consumption calculation

PRINTHEAD
